380kg/800lbs DC12V or DC24V Power to Lock Fail
380kg/800lbs DC12V or DC24V Power to lock Fail-safe door lock system for access cotrol Overview NE-380ST single door wat
Basic Info.
Model NO. | NE-380ST door lock system |
Backset | No Size Limit |
Door Thickness Fits | Unlimited |
Lock Cylinder Length | Without |
Usage | Household Door Locks, Channel Lock, Gate Door Lock;Garage Door Lock |
Surface Finish for Magnet | Zinc Plated |
Optional Functions | Buzzer |
Armature Plate Dimensions(L X W X D) | 190lx39wx11h(mm) |
Weight in Kg | 2.6kg |
Magnets Dimensions(L X W X D) | 285lx55wx29h(mm) |
Relock Delay Timer | 0,3,6,9 Seconds Open Time Delay Is Adjustable |
Rated Operating Voltage | 12/24VDC |
Lock Status Sensors | Yes |
Holding Force | 380kg(800lbs) |
Lock Status Indicator | Red and Green, Double Color LED |
Transport Package | Standard CTN Box |
Specification | 285L*55W*29H(mm) |
Trademark | NORDSON |
Origin | Guangdong Province, China |
Production Capacity | 50000 |
Product Description
380kg/800lbs DC12V or DC24V Power to lock Fail-safe door lock system for access cotrolOverview
NE-380ST single door waterproof magnetic lock,with the door status signal output ,led indicates and time delay,specially used to normal glass door,wodden door,metal door,fire doors,and all kinds of door.Hoisting design,saves time and power when installation.Inward door,frameless glass door,narrow door all have a complete set of accessories.Special Anti-residual magnetic design makes automatic access control safer.
Specification
Holding Force | 380kg(800Lbs) |
Lock Status Indicator | Red and Green, double color LED |
Relock Delay Timer | 0,3,6,9 seconds open time delay is adjustable |
Lock Status Sensors | YES |
Rated Operating Voltage | 12/24VDC |
Current consumption | 12V/500mA 24V/250mA |
Optional Functions | Buzzer |
Surface finish for magnet | Zinc plated |
Surface finish for armature plate | Zinc plated |
Ambient temperature in °C | -10~+55ºC(14-131F) |
Suitable for | Wooden & Aluminum & Glass & Fireproof &Metal |
Magnets Dimensions(L x W x D) | 285Lx55Wx29H(mm) |
Armature Plate Dimensions(L x W x D) | 190Lx39Wx11H(mm) |
Weight in kg | 2.6kg |
CE-mark for building | Yes |
Rohs-mark for building | Yes |
